用途：
用于夹持符合DIN 1880标准的面铣刀和带有径向驱动
键的刀具，也可夹持符合DIN2079直径超过40mm的
刀盘(4个附加的螺孔)
Use:
For clamping face mill cutters and milling cutters with radial driving slot
DIN 1880 and exceeding clamping diameter 40 clamping according to
DIN 2079 is possible, too (4 additional thread holes).
Coolant exit bores on the end face for milling cutters with central cooling.
Similar to DIN 6357 with taper SK40 form ADB DIN 69871.
Form ADB means: central coolant supply and coolant channels on the collar
which can be sealed again.
– Included in delivery: tightening bolt, size 16.1 with reduced contact
diameter
ADB型SK锥柄符合DIN69871
ADB型：中心冷却或可密封的法兰冷却
– 交货时
用途
：
用于夹持符合DIN 1880标准的面铣刀和带有径向驱动键的刀具，
也可夹持符合DIN2079直径超过40mm的刀盘(4个附加􂲴􃷪􁆄􀀌
Use:
For holding face mill cutters and cutters with radial driving slot DIN 1880 and
exceeding clamping diameter 40 clamping according to DIN 2079 is possible,
too (4 additional tapping holes).
According to DIN 6357 with taper SK50 form ADB DIN 69871.
Form ADB means: central coolant supply and coolant channels on the collar
which can be sealed again.
– Included in delivery: tightening bolt
– Coolant bores against extra charge
ADB型SK锥柄符合DIN69871
ADB型：中心冷却或可密封的法兰冷却
– 交货时含：拉紧螺钉
– 冷却喷孔需额外费用
